Halfmile’s Smartphone Apps Updated

The Halfmile’s Pacific Crest Trail apps for both iPhones and Android smartphone have recently been updated. The apps are available free from Apple’s iTunes Store or Google Play.

The updated Halfmile Android app includes 2014 data and minor bug fixes.

The updated Halfmile Android app includes 2014 Halfmile data and minor bug fixes.

The iPhone Halmile app includes a cool new Trail Diagram mode, simplified user interface, and the latest 2014 Halfmile data.

The iPhone Halmile app includes a cool new Trail Diagram mode.

The updated iPhone app includes a cool new “Trail Diagram” mode, simplified user interface, and the latest 2014 Halfmile data.

The updated Android app includes the latest 2014 Halfmile data and Minor bug fixes.

Both apps are designed to be a companion to Halfmile’s Pacific Crest Trail printed map set to aid navigation on the PCT. The app determines your location and, if on the PCT or one of its side trails, it calculates trail distances to 1,700 PCT landmarks and presents any trail notes relevant for the location.

Features of both apps include:

  • Simulation mode for hike planning and hiker support
  • Provides specific “how to walk there” instructions for all points
  • Live trail diagram with optional compass orientation
  • Calculates cumulative elevation gains and losses to all points
  • Powerful search function for features like water sources, campsites, and resupply locations
  • Calculates which printed map pages contain your location
  • Works without cell phone service
  • Download and Go — no extra configuration or data needed

Elevation Gain on the Pacific Crest Trail

elevation profiles

Halfmile’s PCT Map elevation profiles.

Pacific Crest Trail hikers are often interested in knowing the elevation gained or lost as they hike along the Pacific Crest Trail. The 2014 Halfmile Project estimates the total elevation gain/lost for a northbound thru-hiker is 489,418 feet of climbing and 488,411 feet descending with an overall change of 1,007 feet as they hike from Campo to Manning Park.

Here is a breakdown of elevation gain/loss by PCT section:

Gain Loss Change
CA_Sec_A 16,452 -16,335 117
CA_Sec_B 19,006 -20,698 -1,692
CA_Sec_C 22,427 -20,775 1,652
CA_Sec_D 26,944 -27,403 -459
CA_Sec_E 21,200 -19,894 1,306
CA_Sec_F 14,891 -13,469 1,422
CA_Sec_G 23,576 -18,061 5,515
CA_Sec_H 32,804 -34,987 -2,183
CA_Sec_I 14,320 -13,257 1,063
CA_Sec_J 14,049 -16,282 -2,233
CA_Sec_K 10,661 -10,887 -226
CA_Sec_L 5,282 -7,893 -2,612
CA_Sec_M 18,095 -20,421 -2,326
CA_Sec_N 17,106 -16,424 682
CA_Sec_O 17,961 -18,747 -785
CA_Sec_P 19,147 -15,326 3,821
CA_Sec_Q 9,311 -13,918 -4,608
CA_Sec_R 14,290 -11,390 2,900
OR_Sec_B 8,124 -7,427 697
OR_Sec_C 9,008 -8,056 951
OR_Sec_D 7,588 -8,422 -834
OR_Sec_E 9,614 -9,394 220
OR_Sec_F 15,476 -16,619 -1,144
OR_Sec_G 8,965 -12,924 -3,958
WA_Sec_H 29,552 -25,348 4,204
WA_Sec_I 18,327 -19,744 -1,417
WA_Sec_J 18,773 -17,711 1,062
WA_Sec_K 31,441 -30,641 799
WA_Sec_L 15,030 -15,958 -928
Total 489,418 488,411 1,007

It turns out that estimating elevation gain/loss is a surprisingly complex and technical process. The Halfmile Project has put a great deal of effort into this, and our estimates are much more accurate than, say, the ones that Google Earth produces, or any other source of PCT information.

Elevation values obtained from GPS units are much too noisy for use in gain/loss calculations — even from the survey grade equipment that we now are using on the Halfmile Project. Instead, elevation data is based on USGS 1/3 arc second DEM (Digital Elevation Model) data.

Halfmile Project gain/loss estimates use approximately 3/4 million GPS sample points along the Pacific Crest Trail. The elevation for each sample points is calculated based on a grid of 525 USGS 1/3 arc second DEM rectangles that surround the point. A two dimensional spline interpolation is then generated using the DEM rectangles to calculate the exact elevation of each sample point.

elevation spline plot

Blue lines are the elevation spline plots calculated based on 525 USGS DEM elevation rectangles. The center of each DEM rectangle is marked with a black dot. The elevation of a GPS sample point is then calculated, in this example as 1,252.04 meters. The process is repeated about 3/4 million times.

Observant (or obsessed) readers may have noticed that the Halfmile Project elevation estimates changed slightly from 2013 to 2014. This year’s total elevation gain of 489,418 feet is slightly less than the 492,871 foot estimate last year. The reason for the changes are:

  • The DEM data itself is constantly being updated and improved by the USGS.
  • In some sections of the PCT we completely replaced the data with more accurate GPS data.
  • In all sections we changed our selection of points (i.e., doing a bit smarter job this year).
  • Last year’s interpolation was from a grid of 36 surrounding points and this year 525 grid points were used.

While these changes are very small, even small changes add up over thousands of points.

One reason we put so much effort into elevation calculations, is so that the elevation gain/loss estimates match between the printed maps and smart phone apps. The Halfmile smartphone apps calculate very accurate elevation gain/loss estimates between your current on-trail location and any landmark along the trail.

Here the Halfmile smartphone app estimates an elevation gain of 7,102 feet and a loss of 4,047 feet from the Southern Terminus to the water fountain on Mt Laguna near Burn Rancheria Campground.

The Halfmile smartphone app estimates an elevation gain of 7,102 feet and a loss of 4,047 feet along the Pacific Crest Trail from the Southern Terminus to the water fountain near the Burn Rancheria Campground.

If you want even more details about Halfmile Project elevation estimates, David Lippke AKA White Jeep posted a detailed summary recently on the PCT-L. Here is a copy of what he posted:

Hi, Lon alerted me regarding the PCT elevation gain/loss stats conversation here and so I thought some direct information might help. I’m the author and maintainer of the Halfmile apps and I generated all the elevation data and gain/loss numbers published for the last three annual cycles. I spend most of my time working on improving both the horizontal and vertical accuracy of all our PCT data. This effort has ballooned over the last couple years involving more than just myself and Halfmile with the deployment of survey grade equipment to the trail, custom GPS logging devices, and now further generations of all that we are scrambling to deploy for the 2014 season.

Anyway, people often wonder how we calculate elevation gain and loss numbers along the PCT. It turns out that this is a surprisingly complex and technical process. The net is that we currently generate profiles that are much more accurate than, say, the ones that Google Earth produces. That said, there is still substantial room for improvement and we are working on that.

The technical TLDR is that our point elevation values are produced by heavily processing USGS DEM 1/3 arc second data. Our gain / loss calculations then operate over this set using a smoothing factor consistent with the average error present in the DEM data and the average horizontal “side to side” path jitter observed along side slopes.

Most will want to stop reading here. 100% tech talk follows. You have been warned. 🙂

Going on in more detail, the process does not involve using GPS elevation data at all. As noted by Brick, elevation values obtained from GPS units are much too noisy for use in gain and loss calculations — even from the survey grade equipment that we now use. Instead, our raw source for elevation data is the USGS 1/3 arc second DEM (Digital Elevation Model) which provides average elevation values over rectangles that are approximately 8×10 meters on a side (the “8” varies with latitude).

We start with our best filtered GPS horizontal data for each bit of trail. This ranges in horizontal accuracy from 1/2 meter (California sections L through O) to 3-5 meter accuracy (e.g., WA J) to unknown accuracy data that we hand select from the competing data sets. Over 2014 for the 2015 update, we hope to bring the average horizontal accuracy for the entire PCT to the vicinity of a single meter.

Then we translate all those horizontal points to the horizontal datum used by the USGS and we fetch the DEM elevation values needed generate a grid of 525 points surrounding each subject point. Using those 525 points, we generate a two dimensional spline interpolation and query it at the exact point. This process is repeated for all 3/4 million horizontal data points and involves almost 11 million unique 1/3 arc second DEM values.

So at this point in the process we have the best possible estimate for the elevation of each track point and way point expressed in terms of the NAVD88 vertical datum (quasi MSL) with the primary error sources being that of the USGS DEM (RMSE ~2.5 meters) and that of our collected horizontal positions.

In the next step, we reduce the horizontal point count so that all sections stay within Garmin’s 10K track point limit. We do this by applying the Ramer-Douglas-Peucker algorithm with a 1.9 meter sigma overall and, in more accurate sections, a 1.25 meter sigma. In other words, when the trail is going along a straight road or the aquaduct, the points can be several hundred meters apart but in tight turns they may only be a couple meters apart.

Finally, to calculate gains and losses between points, a tally is kept from track point to track point except that no gain or loss is recorded until a track point is reached that has an elevation loss or gain more than 5 meters from the starting track point. When that occurs, the algorithm moves forward to the current end track point and picks up the counting again. When reporting the gain / loss to a particular way point, any residual in the smoothing is closed out so that the numbers all “add up”. As a side note, this creates a small numerical issue when one decides to total our published per-section numbers over the whole trail and compare those to the whole trail numbers in the (soon to be released) 2014 version of the Halfmile apps — our per-section numbers are “closed out” with respect to this 5 meter smoothing but the app just keeps rolling through the boundaries.

Sorry for the tech talk, but I just wanted to address all the speculation about what feeds into these calculations. Questions are always welcome and so is project involvement — we have all manner of “task” available for the inclined. 🙂

All the best,
David Lippke aka White Jeep

Halfmile’s updated 2014 maps are online

Halfmile’s Pacific Crest Trail maps have been updated for the 2014 hiking season and are now online as free .PDF downloads. The updated maps include suggestions from 2013 hikers, more than 400 miles of new GPS data collected with survey grade GPS equipment in California Sections L – M, and new smaller files optimized for mobile devices (in addition to standard files optimized for 8 1/2 x 11 printing).
